Copper Bonded Chemical Earthing Electrode
-
Copper coated rod as per standard, Long Service life
-
100 to 250 micron thick copper coating.
-
Inner flat electrode is copper coated.
-
More than 15 years of durability.
-
Very High conductivity, corrosion resistant.
-
Inner filled Crystalline conductive Compound.
| Model | Rod Diameter (mm) | Length (Meter) | Copper Bonding |
|---|---|---|---|
| iTorrent-48/CBR | 48 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| iTorrent-76/CBR | 76 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| TESTED FROM NABL & CPRI LAB. | |||
GI-Earth Electrode
-
Hot dip galvanized for corrosion protection.
-
Moisture booster chemical bags provided for low earth resistance.
-
Designed for fast fault current dissipation.
-
Easy & Fast installation on site.
-
Low maintenance on site.
-
Most suitable for soil condition with pH value 5.0 & 8.0.
| Model | Rod Diameter (mm) | Length (Meter) | |
|---|---|---|---|
| iTorrent-48/GIR | 48 mm | 1, 2 & 3 mtr | |
| iTorrent-58/GIR | 58 mm | 1, 2 & 3 mtr | |
| iTorrent-76/GIR | 76 mm | 1, 2 & 3 mtr | |
| TESTED FROM NABL & CPRI LAB. | |||
Copper Bonded Solid Earth Rod
-
Copper coated rod as per standard.
-
100 to 250 micron thick copper coating.
-
Highly conductive and anti-corrosive.
-
More than 15 years of durability.
-
This conductor is high strength, Excellent elasticity
| Model | Rod Diameter (mm) | Length (Meter) | Copper Bonding |
|---|---|---|---|
| iTorrent-14.2/CBR | 14.2 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| iTorrent-17.2/CBR | 17.2 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| iTorrent-20/CBR | 20 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| iTorrent-25/CBR | 25 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| iTorrent-32/CBR | 32 mm | 1, 2 & 3 mtr | 100 to 250 micron |
| TESTED FROM NABL & CPRI LAB. | |||
Pure Copper Earth Electrode & Rod
-
Used 100% copper for long life.
-
Designed for fast fault current dissipation.
-
Low maintenances on site.
-
Easy & Fast installation on site.
-
Most suitable for soil condition with pH value 5.0 & 8.0.
-
Moisture booster chemical bags provided for low earth resistance.
| Model | Rod Diameter (mm) | Length (Meter) | |
|---|---|---|---|
| iTorrent-48/PCR | 48 mm | 1, 2 & 3 mtr | |
| iTorrent-76/PCR | 76 mm | 1, 2 & 3 mtr | |
| TESTED FROM NABL & CPRI LAB. | |||
